FEATURES

• Connectors: Redesigned Speaker Terminals for Easy Installation

• Terminal Layout: One-Sided
• Mounting Design: Easy Stacking and Clean-look installation

General

• Built-in Variable High/Low Pass Filter
• Variable Subsonic Filter (Mono Channel)
• Bass EQ
• Aluminium Heat Sink
• All-new SIERRA Digital Design
• Remote Sensing
• Remote Level Control with Optional RUX-KNOB or RUX-KNOB.2
• RCA Speaker Connection (Optional KCE-SP2R)

SPECIFICATIONS

• 100W RMS x 4 + 500W x 1 [2Ω@14.4V]
• 75W RMS x 4 + 300W x 1 [4Ω@14.4V]
• THD+N (Reference: 10W / rated power into 4 ohms): 0.02%
• S/N Ratio: (IHF A Weighted, Reference: rated power into 4 ohms): >87 dBA
• S/N Ratio: (IHF A Weighted, Reference: 1 W into 4 ohms): >80 dBA
• Input Impedance: 10k ohms
• Frequency Response (Reference: 1 W into 4 ohms):  8Hz – 400 kHz
• Damping Factor (Reference: 1 W into 4 ohms at 100Hz): >1,000

• Width: 297.0 mm
• Height: 50.8 mm
• Depth: 192.0 mm
• Weight: 3.2 kg
