FEATURES Install- Connectors: Redesigned Speaker Terminals for Easy Installation
- Terminal Layout: One-Sided
- Mounting Design: Easy Stacking and Clean-look installation
General - Built-in Variable High/Low Pass Filter
- Bass EQ
- Aluminium Heat Sink
- All-new SIERRA Digital Design
- Remote Sensing
- Remote Level Control with Optional RUX-KNOB.2
- RCA Speaker Connection (Optional KCE-SP2R)
|
SPECIFICATIONS RMS Continuous Power (at 14.4 V)- 175W RMS x 4 [2Ω@14.4V]
- 120W RMS x 4 [4Ω@14.4V]
- THD+N (Reference: 10W / rated power into 4 ohms): 0.02%
- S/N Ratio: (IHF A Weighted, Reference: rated power into 4 ohms): >106 dBA
- S/N Ratio: (IHF A Weighted, Reference: 1 W into 4 ohms): >87 dBA
- Input Impedance: 10k ohms
- Frequency Response (Reference: 1 W into 4 ohms): 10Hz – 60 kHz
- Damping Factor (Reference: 10 W into 4 ohms at 100Hz): >500
Dimensions - Width: 297.0 mm
- Height: 50.8 mm
- Depth: 192.0 mm
- Weight: 3.2 kg
|
