4-Channel Bridgeable Amplifier
| GENERAL | |
| RCA Inputs | 4-CH |
|---|---|
| Amplifier Class | Class AB |
| Hi-Res Certified | No |
| Bridgeable | Yes |
| Warranty | 1 Year |
| Speaker Level Input | Yes |
| Fuse Rating | 30A x 1 |
| Bass Boost Remote | No |
| Automatic Signal Sensing and Turn-On | Yes |
| Hi-Volt Input Level Control | 0.3V to 6.5V (RCA in), 3.0V to 26V (SP in) |
| Terminal Type | Screw |
| Load Impedance Allowance (Ohms) | 2 to 4 |
| Protection Control System | Yes |
| Dimensions | 326(W) X 60(H) X 215(D) mm |
| POWER | |
| Continuous Power (RMS) Output @ 1Ω | N/A |
| Continuous Power (RMS) Output @ 2Ω | 65W x 4 |
| Continuous Power (RMS) Output @ 4Ω | 40W x 4 |
| Continuous Power (RMS) Output - Bridged @ 4Ω | 130W x 2 |
| AUDIO ADJUSTMENTS | |
| Low-Pass Crossover Frequency | 80 Hz |
| Low-Pass Slope (dB/octave) | -12db/oct (A/B CH) |
| High-Pass Crossover Frequency | 40 Hz to 500 Hz |
| Bass Boost Frequency | 50Hz |
| Bass Boost Level | 0/6/12dB |
| AUDIO SPECIFICATIONS | |
| Frequency Response | 10Hz ~ 70kHz (+0dB , -3dB) |
| Total Harmonic Distortion (THD) | <0.05% ( 10W, 1kHz) |
| Signal-to-Noise (SN) Ratio | > 94dB |
